About Online Stack Gas Analyzer
The Online Stack Gas Analyzer delivers rapid, precise emissions monitoring with a swift 30-second response time. Weighing 60 kg, it operates efficiently on 230 V AC power under ambient temperature and up to 95% RH humidity, ensuring durability in harsh environments. Featuring RS-485 communication for seamless data integration, it accurately measures gas concentrations up to 1000 mg/Nm3. Ideal for industries like power plants, cement, steel, and chemical manufacturing, this analyzer ensures regulatory compliance, optimizes combustion efficiency, and supports environmental monitoring by providing real-time, reliable gas analysis.
| Brand | Soarmlich Engineers |
| Usage/Application | Emission Monitoring |
| Product Type | Continues Emission Monitoring System |
| Power Supply | 230 V AC |
| Analysis Time | 30 Sec. |
| Automation Grade | Automatic |
| Response Time | 30 second |
| Weight | 60 kg |
| Power | 230 V AC |
| Temperature | Ambient |
| Humidity | 95% RH |
| Communication | RS-485 |
| Measuring Range | 1000 mg/Nm3 |
| Inlet Pressure | 1 LPM |
| Measurable Gases | SO2,NOx,PM,O2,CO,CO2, etc... |
| Memory | 128 GB |
| Dimension | 570 x 600 x 370 mm |
| Power Source | UPS Based |
| Analog Output | 4-20 mA |
| Make | Soar Mlich Engineers |
| Drift | +/- 2% |
| Range | 0-1000 mg/Nm3 |
| Resolution Ratio | 0.1 mg/Nm3 |
| Least Count | 1 |
| Response Speed | within 90 Second |
| Calibration Intervals | 6 Month |
| Measurement Gas Dust | SO2/NOx/O2/CO/CO2 |
| Output Signal | RS-485 |
| Analog Input | 4-20 mA |
| Warranty | 1 Year |
| Mounting | Stand Mounting |
| Sensor Life | 3 to 5 years |
| Accuracy | +/- 2% |
| Touch Screen | Yes |
| USB Ports | Yes |
| Wattage | 400 W |
| Enclosure | 19" Rack |
| Operating Temp | - 20 to + 250 Degree Celsius |
| Frequency | 60 Hz |
| Country of Origin | Made in India |
| Mounting Type | Panel Mount |
| Model Name/Number | CEMS-209-IR |
| Display Type | Touch Screen Display |
Advanced Gas Detection TechnologyLeveraging infrared technology, the CEMS-209-IR can simultaneously monitor multiple gases including SO2, NOx, O2, CO, and CO2, making it essential for comprehensive emission assessments. Its high accuracy and low drift, combined with robust communication options like RS-485 and USB, deliver superior, actionable data for industrial operators and environmental compliance teams alike.
User-Centric Design and DurabilityFeaturing a touch screen interface housed within a 19-inch rack enclosure, the analyzer prioritizes ease of use and robustness. With an operating temperature range from -20 to +250C and a humidity tolerance up to 95% RH, it is built to withstand harsh industrial conditions, ensuring longevity and reliability.
Long-Term Efficiency and MaintenanceThe analyzer requires calibration only every six months and offers a sensor lifespan of 3 to 5 years, minimizing downtime and maintenance costs. Its UPS-based power supply ensures uninterrupted operation, further enhancing reliability in continuous emission monitoring applications.
FAQ's of Online Stack Gas Analyzer:
Q: How does the CEMS-209-IR Online Stack Gas Analyzer operate in harsh industrial environments?
A: This analyzer is engineered with a rugged enclosure and can function across a wide temperature range of -20 to +250C and up to 95% relative humidity. Its robust construction allows reliable performance in demanding industrial and emission monitoring applications.
Q: What gases can be measured using the CEMS-209-IR analyzer?
A: The device can simultaneously measure key industrial pollutants, including SO2, NOx, O2, CO, CO2, PM, and more. It is suitable for emission monitoring of a variety of gaseous components in stack gases.
Q: When should the analyzer be calibrated, and how is the process managed?
A: Calibration should be performed every six months. The process is automated to ensure accuracy, and maintenance is minimal thanks to the analyzer's advanced design and sensor stability.
Q: Where is the CEMS-209-IR typically installed and how is it mounted?
A: The analyzer is most commonly installed in industrial facilities, fitted into a 19-inch rack using the provided panel mounting system. This ensures secure placement near emission sources for direct and efficient monitoring.
Q: What are the primary benefits of using the CEMS-209-IR gas analyzer?
A: Benefits include fast response time (within 30 seconds), high measurement accuracy (+/- 2%), extended sensor life (3 to 5 years), large 128 GB data memory, and seamless data communication via RS-485 and USB ports. This ensures reliable, continuous compliance with regulatory emission limits.
Q: How is data accessed and exported from the analyzer?
A: Data can be accessed in real-time through the touch screen display or exported directly using USB ports or RS-485 communication. The analyzer also supports analog output (4-20 mA) for integration with external monitoring systems.
Q: What kind of power supply and backup does the analyzer use?
A: Power is supplied via 230 V AC and is backed up by a UPS-based system, ensuring continuous operation even in the event of a power outage.
